25kw 31kva Weichai Diesel Generator Set

Diesel Generator Set Data

Model: DB-25GF

Prime power: 25KW/31.25KVA

Rated current: 45A

Rated frequency: 50Hz

Power factor: 0.8lag

Rated voltage: 230/400V

Transport package: plastic film/ plywood case

Delivery time: within 15-20 days


For more types, please contact us


Share:


High quality 25kw Weichai diesel generator set approved by CE and ISO certificate.


1. Originated from European technology, independent research and development.

2. Industry-leading product performance indicators.

3. High reliability, low emission, low noise.

4. Professional generator set application integration capabilities.

5. Structural/functional solutions suitable for multiple application scenarios.

6. Possess various domestic product certification qualifications and CE certification.

7. Using electronically controlled high-pressure common rail technology, emissions reach the national III emission standard.

8. CE and ISO certificate

9.Warranty: 12 months or 1000 running hours after delivery, whichever comes first.

Why Choose Us

Dingbo is original manufacturer of diesel generator set. Factory direct sale, guaranteed quality and affordable price.



Our diesel generator sets are widely used in telecommunications, energy, transportation, real estate, hospital, residential building, data center and other fields, having long-term strategic cooperation with a lot of well-known enterprises. From research and development to production, from raw material procurement, assembly and processing to finished product debugging and testing, each process is strictly implemented, in all aspects meet the national, industry standards and contract provisions of the quality, specifications and performance requirements.



We have a professional and technical team, with an average working experience of more than 10 years in the generator industry. In the spirit of "keep improving", they actively collect and attract advanced technology and products at home and abroad, and constantly update the products, so that our diesel generators have been recognized by the majority of users.



If a customer can not find his supplier to support them when equipment has problem, after sales service is not guaranteed, which is a very helpless thing. While we have perfect after-sales service to support you to solve problem, it's not that you can't find us after you have a problem on your equipment. We will be with you and solve your problems with heart.


Export Case

So far, our diesel genset sold to Ethiopia, Venezuela, Singapore, Nigeria, Thailand, U.S.A etc. all over the world, both having good feedback from customers.

Diesel generators


Specific Project Cases:

https://www.dbdieselgenerator.com/project-case/

FAQ

1. Do you have your own factory?

Yes, we have. Welcome to visit our factory.

2. What is the delivery time and do you have product in stock?

Delivery time depends on order quantity. Generally, within 10 days for open genset, 20 days for silent genset. We have some power capacities in stock, if need details, please contact us.

3. What is your warranty period?

Our warranty is 1 year or 1000running hours whichever comes first. But based on some special project, we can extended our warranty period.

4. Does your generator have global warranty?

Yes, We supply the warranty. Also most of our products like Cummins, Volvo, Perkins, Deutz, Doosan, Yuchai, Weichai etc. power generator enjoy the global warranty service. And the alternator we use like Stamford and marathon also enjoy the global warranty service, so you do not need to worry about the after-sales service.

5. What is your payment terms?

We can accept T/T 30% in advance, and the balance 70% shall be paid before shipment or L/C at sight. But based on some special project and special order, we can do something on payment item.

6. Do you provide OEM service?

Yes, we can put your company logo on our diesel genset, just tell us your requirements, then we will do it for you.

Our Service

Before service

Our professional engineer will give you some consultation of technology and related planning before sale, such as selection of equipment, supporting facilities, the design of equipment room. We can also answer and solve the using problem you faced.



After sale service

1. Free guide to install and debugging

2. Free training and consult

3. Guiding how to protect your equipment

4. We will set up clients' document, tracking service, regular inspection, maintenance for life

5. We offers pure perennial spare parts and maintenance engineers will be ready to provide.

Dingbo Cloud on line service will help you to manage your equipment, save cost and improve efficiency.

Product Advantage

Emission: non-road three-stage emissions

Power: high power density

Economy: low fuel consumption

Comfort: low noise, low vibration


More economics

The engine's usual working range (50%-80%) runs in the lowest fuel consumption area.

Improve the engine speed, the power density is large, the power of the same displacement is increased by 49% compared with the competition, and the complete set of the unit is low in cost.


More environmentally friendly

Meet the national non-road emission standards Stage III. Green, low-carbon and environmentally friendly.

Diesel Generator Set Data
Manufacturer:Guangxi Dingbo Generator Set Manufacturing Co.,Ltd  Co.,Ltd
Set Type:DB-25GF

Prime Power:

Standby Power:

25KW/31.25KVA

26KW/32.5KVA

Rated Current:45(A)
Rated Frequency:50(Hz)
Start-up time:5~6(s)
Power Factor:0.8(Lag)
Rated Voltage:400/230(V)
Standard Features

Engine: Weichai WP2.3D33E200

Radiator 40℃

Fans are driven by belt, with safety guard

24V charge alternator

Dry type air filter, fuel filter, oil filter

Alternator: single bearing alternator, IP22-IP23, insulation class H/H

Main line circuit breaker

Standard control panel

AbsorberMuffler

Factory test report, User manual etc.

Diesel Engine Data
Manufacturer:Weichai Power Yangzhou Diesel Engine Co Ltd.
Model:WP2.3D33E200
Prime/Standby Power:30KW/33KW
Rated Speed:1500(r/min)
Cycle:4 stroke
Cylinder Arrangement:4 in line
Displacement:2.289L
Bore and Stroke:89*92(mm)
Compression Ratio:17.5:1
Governor Type:Mechanical speed governor
Start battery voltage:12V DC Electrical Start
Air Intake System
Air Intake System:Turbocharged
Min Intake Restriction:100kpa
Exhaust System
Max. Exhaust Temperature:650℃
Max Allowable Back Pressure:8kpa
Fuel System
Fuel System:Direct injection
100%( Prime Power) Load:215g/kw.h
50%( Prime Power) Load:199g/kw.h
Oil System
Total Oil Capacity:8L
Oil Consumption ratio:<0.1%
Cooling System
Cooling Way:Water-cooled
Total Coolant Capacity:5L
Thermostat:70-85℃
Max Water Temperature:102℃
Alternator Data
Manufacturer:STAMFORD/SIEMENS/MARATHON/ENGGA /LEROY SOMER
Excitation Mode:Brushless and self- exciting
Number of phase and Access Act:3-phase 4-wire
Connecting Type:“Y” type connecting
Alternator Capacity:31.25KVA
Alternator Efficiencies:95%
Overload:Oerload running 1 hour within 12 hours
Protection Level:IP22-IP23
Insulation Class, Temperature Rise:H/H
Telephone Influence Factor (TIF):<50
THF:<2%
Voltage Regulation, Steady State:≤±1%
Altitude:≤1000m
Genset Electrical Performance
Voltage Regulation:≥±5%
Voltage Regulation, Stead State:≤±1%
Sudden Voltage Warp (100% Sudden Reduce):≤+25%
Sudden Voltage Warp (Sudden Increase):≤-20%
Voltage Stable Time (100% Sudden Reduce):≤6S
Voltage Stable Time (Sudden Increase):≤6S
Frequency Regulation, Stead State:≤5%
Frequency Waving:≤1.5%
Sudden Frequency Warp (100% Sudden Reduce):≤+12%
Sudden Frequency Warp (Sudden Increase):≤-10%
Frequency Recovery Time(100%Sudden Reduce):≤5S
Frequency Recovery Time(Sudden Increase):≤5S
Options
EngineAlternator
HeaterAnti Condensation Heater
Battery ChargerPermanent Magnet Generator(PMG)
Water SeparatorDrop CT(For Paralleling)
Daily Fuel Tank
Fuel Level Sensor
Control SystemOthers
Remote Control PanelRainproof Type
Auto Transfer Switch (ATS)Soundproof Type
Paralleling SystemTrailer Type
Open Type
Overall SizeWeight
1730*750*1190(mm)640(kg)
Soundproof Type
Overall SizeWeight
2500*1100*1450(mm)1000(kg)


More technical information, please send inquiry to us.

Genset ModelGenerating Set OutputEngine ModelSize
Prime PowerStandby Power

Dimension

(L x W x H:mm)

Weight

( kg )

KWKVAKWKVA
DB-25GF25312835WP2.3D33E2001600×760×1200620
DB-30GF30383341WP2.3D40E2001680×760×1200680
DB-40GF40504455WP2.3D48E2001750×760×1350720
DB-50GF50635569WP4.1D66E2001950×950×1400860
DB-50GF50635569WP4D66E2001950×950×1400960
DB-80GF8010090113WP4.1D100E2002100×950×15001130
DB-80GF8010090113WP4.1D100E2002100×950×15001150
DB-80GF8010090113WP4D100E2002200×950×15001020
DB-90GF90113100125WP4D108E2002200×950×15001180
DB-100GF100125110138WP6D132E2002400×950×15001330
DB-120GF120150132165WP6D152E2002400×950×15001400
DB-160GF160200180225WP10D200E2002900×1200×18001800
DB-200GF200250220275WP10D238E2002900×1200×18001980
DB-200GF200250220275WP10D264E2002900×1200×18002200
DB-250GF250313280350WP10D320E2003000×1200×20002380
DB-260GF260325280350WP12D317E2003000×1200×20002550
DB-300GF300375330413WP13D385E2003050×1250×21002820
DB-320GF320400352440WP13D405E2003050×1250×21003500
DB-350GF350438385481WP13D440E3103050×1250×21003680


Genset ModelGenerating Set OutputEngine ModelSize
Prime PowerStandby Power

Dimension

(L x W x H:mm)

Weight

( kg )

KWKVAKWKVA
DB-25GF25312835WP2.3D33E2001600×760×1200620
DB-30GF30383341WP2.3D40E2001680×760×1200680
DB-40GF40504455WP2.3D48E2001750×760×1350720
DB-50GF50635569WP4.1D66E2001950×950×1400860
DB-50GF50635569WP4D66E2001950×950×1400960
DB-80GF8010090113WP4.1D100E2002100×950×15001130
DB-80GF8010090113WP4.1D100E2002100×950×15001150
DB-80GF8010090113WP4D100E2002200×950×15001020
DB-90GF90113100125WP4D108E2002200×950×15001180
DB-100GF100125110138WP6D132E2002400×950×15001330
DB-120GF120150132165WP6D152E2002400×950×15001400
DB-160GF160200180225WP10D200E2002900×1200×18001800
DB-200GF200250220275WP10D238E2002900×1200×18001980
DB-200GF200250220275WP10D264E2002900×1200×18002200
DB-250GF250313280350WP10D320E2003000×1200×20002380
DB-260GF260325280350WP12D317E2003000×1200×20002550
DB-300GF300375330413WP13D385E2003050×1250×21002820
DB-320GF320400352440WP13D405E2003050×1250×21003500
DB-350GF350438385481WP13D440E3103050×1250×21003680
