320kw 400kva Weichai Diesel Generator Set

Diesel Generator Set Data

Model: DB-320GF

Prime power: 320KW/400KVA

Rated current: 576A

Rated frequency: 50Hz

Power factor: 0.8lag

Rated voltage: 230/400V

Transport package: plastic film/ plywood case

Delivery time: within 15-20 days


For more types, please contact us


Share:

1. The king of cost-effective power


2.Ultra low fuel consumption

Optimize the engine intake and fuel system, explore the engine potential, focus on optimizing the fuel consumption in the range of 60% ~ 90% load rate, and reduce the fuel consumption.


3.Strong adaptability

Cold adaptability: when the temperature is - 15 ℃, the engine starts directly without auxiliary measures; When the temperature is 40 ℃, the engine can start smoothly by preheating the intake air.


Plateau Adaptability: when the altitude is less than 3000m, the engine can output rated power; When the altitude is greater than 3000m, the engine can work reliably.


4.Good adaptability

The center mounted down turn turbocharger and special flat bottom oil pan are adopted to reduce the height of the whole machine; Compact structure, it is the ideal power of silent diesel genset.


Why Choose Us

Dingbo is original manufacturer of diesel generator set. Factory direct sale, guaranteed quality and affordable price.



Our diesel generator sets are widely used in telecommunications, energy, transportation, real estate, hospital, residential building, data center and other fields, having long-term strategic cooperation with a lot of well-known enterprises. From research and development to production, from raw material procurement, assembly and processing to finished product debugging and testing, each process is strictly implemented, in all aspects meet the national, industry standards and contract provisions of the quality, specifications and performance requirements.



We have a professional and technical team, with an average working experience of more than 10 years in the generator industry. In the spirit of "keep improving", they actively collect and attract advanced technology and products at home and abroad, and constantly update the products, so that our diesel generators have been recognized by the majority of users.



If a customer can not find his supplier to support them when equipment has problem, after sales service is not guaranteed, which is a very helpless thing. While we have perfect after-sales service to support you to solve problem, it's not that you can't find us after you have a problem on your equipment. We will be with you and solve your problems with heart.


Export Case

So far, our diesel genset sold to Ethiopia, Venezuela, Singapore, Nigeria, Thailand, U.S.A etc. all over the world, both having good feedback from customers.

Diesel generators


Specific Project Cases:

https://www.dbdieselgenerator.com/project-case/

FAQ

1. Do you have your own factory?

Yes, we have. Welcome to visit our factory.

2. What is the delivery time and do you have product in stock?

Delivery time depends on order quantity. Generally, within 10 days for open genset, 20 days for silent genset. We have some power capacities in stock, if need details, please contact us.

3. What is your warranty period?

Our warranty is 1 year or 1000running hours whichever comes first. But based on some special project, we can extended our warranty period.

4. Does your generator have global warranty?

Yes, We supply the warranty. Also most of our products like Cummins, Volvo, Perkins, Deutz, Doosan, Yuchai, Weichai etc. power generator enjoy the global warranty service. And the alternator we use like Stamford and marathon also enjoy the global warranty service, so you do not need to worry about the after-sales service.

5. What is your payment terms?

We can accept T/T 30% in advance, and the balance 70% shall be paid before shipment or L/C at sight. But based on some special project and special order, we can do something on payment item.

6. Do you provide OEM service?

Yes, we can put your company logo on our diesel genset, just tell us your requirements, then we will do it for you.

Our Service

Before service

Our professional engineer will give you some consultation of technology and related planning before sale, such as selection of equipment, supporting facilities, the design of equipment room. We can also answer and solve the using problem you faced.



After sale service

1. Free guide to install and debugging

2. Free training and consult

3. Guiding how to protect your equipment

4. We will set up clients' document, tracking service, regular inspection, maintenance for life

5. We offers pure perennial spare parts and maintenance engineers will be ready to provide.

Dingbo Cloud on line service will help you to manage your equipment, save cost and improve efficiency.

Weichai WP13 series engine of our 320kw diesel generator set are high reliability products jointly developed by Weichai European R & D center and AVL. The power covers 290-490kw, meets the third stage of non road emission in China, and forms a new supporting power of 250-400kw land-based generator set.

Diesel Generator Set Data
Manufacturer:Guangxi Dingbo Power Equipment Manufacturing  Co.,Ltd
Set Type:DB-320GF

Prime Power:

Standby Power:

320kW/400kVA

352kW/440kVA

Rated Current:576(A)
Rated Frequency:50(Hz)
Start-up time:5~6(s)
Power Factor:0.8(Lag)
Rated Voltage:400/230(V)
Standard Features

Engine: Weichai WP13D405E200

Radiator 40℃ or 50

 Fans are driven by belt, with safety guard

24V charge alternator

Dry type air filter, fuel filter, oil filter

Alternator: single bearing alternator, IP22-IP23, insulation class H/H

Main line circuit breaker

Standard control panel

AbsorberMuffler

Factory test report, User manual etc.

Diesel Engine Data
Manufacturer:Weichai Power Co.,Ltd
Model:WP13D405E200
Prime/Standby Power:368KW/405KW
Rated Speed:1500(r/min)
Cycle:4 stroke
Cylinder Arrangement:6 cylinders, in line
Displacement:12.54L
Bore and Stroke:127*165(mm)
Compression Ratio:17:1
Governor Type:Electrical speed governor
Start battery voltage:24V DC Electrical Start
Air Intake System
Air Intake System:Turbocharged & Intercooled
Min Intake Restriction:100kpa
Exhaust System
Max. Exhaust Temperature:580℃
Max Allowable Back Pressure:7.5kpa
Fuel System
Fuel System:Direct injection
100%( Prime Power) Load:215g/kw.h
50%( Prime Power) Load:199g/kw.h
Oil System
Total Oil Capacity:36L
Oil Consumption ratio:<0.2%
Cooling System
Cooling Way:Closed water cooled
Total Coolant Capacity:25L
Thermostat:70-85℃
Max Water Temperature:102℃
Alternator Data
Manufacturer:STAMFORD/SIEMENS/MARATHON/ENGGA /LEROY SOMER
Excitation Mode:Brushless and self- exciting
Number of phase and Access Act:3-phase 4-wire
Connecting Type:“Y” type connecting
Alternator Capacity:400KVA
Alternator Efficiencies:95%
Overload:Oerload running 1 hour within 12 hours
Protection Level:IP22-IP23
Insulation Class, Temperature Rise:H/H
Telephone Influence Factor (TIF):<50
THF:<2%
Voltage Regulation, Steady State:≤±1%
Altitude:≤1000m
Genset Electrical Performance
Voltage Regulation:≥±5%
Voltage Regulation, Stead State:≤±1%
Sudden Voltage Warp (100% Sudden Reduce):≤+25%
Sudden Voltage Warp (Sudden Increase):≤-20%
Voltage Stable Time (100% Sudden Reduce):≤6S
Voltage Stable Time (Sudden Increase):≤6S
Frequency Regulation, Stead State:≤5%
Frequency Waving:≤1.5%
Sudden Frequency Warp (100% Sudden Reduce):≤+12%
Sudden Frequency Warp (Sudden Increase):≤-10%
Frequency Recovery Time(100%Sudden Reduce):≤5S
Frequency Recovery Time(Sudden Increase):≤5S
Options
EngineAlternator
HeaterAnti Condensation Heater
Battery ChargerPermanent Magnet Generator(PMG)
Water SeparatorDrop CT(For Paralleling)
Daily Fuel Tank
Fuel Level Sensor
Control SystemOthers
Remote Control PanelRainproof Type
Auto Transfer Switch (ATS)Soundproof Type
Paralleling SystemTrailer Type
Open Type
Overall SizeWeight
3050*1250*2100(mm)3680(kg)
Soundproof Type
Overall SizeWeight
4200*1600*2000(mm)4200(kg)


More technical information, please send inquiry to us.


Genset ModelGenerating Set OutputEngine ModelSize
Prime PowerStandby PowerDimension( L x W x H:mm )Weight( kg )
KWKVAKWKVA
DB-25GF25312835WP2.3D33E2001600×760×1200620
DB-30GF30383341WP2.3D40E2001680×760×1200680
DB-40GF40504455WP2.3D48E2001750×760×1350720
DB-50GF50635569WP4.1D66E2001950×950×1400860
DB-50GF50635569WP4D66E2001950×950×1400960
DB-80GF8010090113WP4.1D100E2002100×950×15001130
DB-80GF8010090113WP4.1D100E2002100×950×15001150
DB-80GF8010090113WP4D100E2002200×950×15001020
DB-90GF90113100125WP4D108E2002200×950×15001180
DB-100GF100125110138WP6D132E2002400×950×15001330
DB-120GF120150132165WP6D152E2002400×950×15001400
DB-160GF160200180225WP10D200E2002900×1200×18001800
DB-200GF200250220275WP10D238E2002900×1200×18001980
DB-200GF200250220275WP10D264E2002900×1200×18002200
DB-250GF250313280350WP10D320E2003000×1200×20002380
DB-260GF260325280350WP12D317E2003000×1200×20002550
DB-300GF300375330413WP13D385E2003050×1250×21002820
DB-320GF320400352440WP13D405E2003050×1250×21003500
DB-350GF350438385481WP13D440E3103050×1250×21003680


Genset ModelGenerating Set OutputEngine ModelSize
Prime PowerStandby PowerDimension( L x W x H:mm )Weight( kg )
KWKVAKWKVA
DB-20GF20252430WP2.3D30E2011600×760×1200620
DB-24GF24302633WP2.3D36E2011680×760×1200680
DB-30GF30383341WP2.3D41E2011750×760×1350720
DB-35GF35444050WP2.3D47E2011950×950×1400860
DB-40GF40505063WP2.3D58E2011950×950×1400960
DB-60GF60756683WP4.1D80E2012100×950×15001130
DB-75GF759480100WP4.1D95E2012100×950×15001150
DB-90GF90113100125WP4.1D115E2012200×950×15001020
DB-100GF100125120150WP6D132E2012400×950×15001330
DB-120GF120150132165WP6D158E2012400×950×15001400
DB-150GF--150188WP6D180E2012900×1200×18001800
DB-150GF150188180225WP6D200E2012900×1200×18001800
DB-250GF--250313WP7D288E3112900×1200×18001980
DB-150GF150188165206WP10D200E2012900×1200×18002200
DB-180GF180225200250WP10D238E2013000×1200×20002380
DB-200GF200250220275WP10D264E2013000×1200×20002550
DB-230GF230288250313WP10D288E2013050×1250×21002820
DB-320GF--320400WP10D360E2013050×1250×21003500
DB-320GF--320400WP10D360E3513050×1250×21003680
DB-300GF300375350438WP13D385E2013050×1250×21003680
DB-360GF360450400500WP13D448E2013050×1250×21003680
