Sixth 200KW Silent Type Gensets Supplied to Guinea Customer

Nov. 25, 2025

Dingbo Power secured the trust of its long-term partner in Guinea once again this November, achieving a sixth repeat order for 200KW silent generator sets. This order not only reflects the depth of our long-term collaboration but also demonstrates the robust capabilities of Dingbo products — engineered with premium components and refined design to ensure high performance and extended service life.


Genset Parameters:

Prime power: 200KW/250KVA
Standby(Max.) Power: 220KW/275KVA
Rated current:380A
Rated voltage:380V
Rated speed/frequency1500rpm/50Hz
Power factor:0.8lag
Phase:3 phase 4 wire
Stable voltage regulation rate≤±0.5%
Volatility≤±0.25%
Transient voltage regulation rate≤+20~-15%
Steady state frequency regulation≤±0.5%
Transient frequency adjustmentrate≤±7%
Frequency adjustment rate≤±1%
Frequency stability time  1s
Voltage stability time≤1s
Base bottom fuel tank360L Base bottom fuel tank


Sixth 200KW Silent Type Gensets Supplied to Guinea Customer


Excellent Power Core: Cummins Diesel Engine


At the core of this 200kW 250kVA diesel generator set, the Cummins 6LTAA8.9-G2 diesel engine delivers trusted performance for heavy-duty use. The 8.9L engine with 50°C radiator guarantees stable power, even in extreme heat.


Engine Parameters

Manufacturer:Dongfeng Cummins Engine Co.,Ltd
Engine model6LTAA8.9-G2
Prime power: 220KW
Standby power:240KW
Frequency/Speed:50Hz/1500RPM
Cylinders no. & Type:6 cylinders, In line, 4 stroke, diesel engine, water-cooled with radiator with fan
Aspiration:Turbo Charge and Charge Air Cooled
Displacement:8.9L
Compression ratio16.6:1
GovernorElectronic speed control
Bore x Stroke(mm):114 x 145
Start mode:Electric start
Starter motor:24V DC, negative ground
Fuel System:Direct injection
Minimum Required Lube System Capacity - Sump plus Filters27.6L
Maximum oil temperature121℃
Cooling wayWater-cooled
Engine coolant capacity11.1L
Standard thermostat (modulating) range83~95℃
Maximum Top Tank Temperature for Standby / Prime Power110/104℃
Fuel consumption@25% / 50% / 75% / 100%(L/h)8/14/20/27
Fuel consumption@110% (L/h)30


Dingbo DB-200 High-Performance Alternator


Featuring Dingbo's DB-200 alternator, this diesel generator set offers 380V/50Hz power with an IP23 rating for dependable performance in harsh, dusty, or humid conditions.



Intelligent Control Hub: Smartgen HGM6110N-4G-G Controller


Equipped with the Smartgen HGM6110N-4G-G controller, the generator set enables intelligent monitoring and protection. The controller features a multi-language interface, emergency stop, and integrated 4G for potential remote monitoring, ensuring both safety and operational convenience.



Dingbo Power's 200KW silent generator set for Guinea features a 2mm galvanized steel canopy with 75dB noise suppression at 7m. The integrated 360L base tank enables extended operation in remote locations. With complete pre-delivery testing, full documentation and plug-and-play installation, this sixth repeat order demonstrates Dingbo's growing reliability in West Africa's power market.



If you also need diesel generator sets, feel free to contact us anytime.
