Manual Of Diesel Generator Set

Because the diesel generator set is not used as a common power supply, nor like the common electrical appliances in the home, almost every day to use, everyone will use. It is used only as a backup power source in the event of a power failure or lack of mains supply, so it is sometimes used less than once or twice a year. But it is necessary when it is really needed; At this point, if the professional operator is not on site, how does the rookie start the diesel generator set? Below, the front power for not using the generator set, or the first time to use the generator set, how to start the generator set to make a simple explanation, so that a novice level of people can also operate the diesel generator set in a few minutes.

First of all, the diesel generator sets manufactured by FUfa Power are standard configuration, all with a start button, with automatic start, automatic stop and automatic fault protection function. The generator battery, muffler, shock cushion and so on have all been configured.

1. Before starting, check whether all parts of the diesel engine are normal, check the water level of the water tank (liquid level should be as close as possible to the cover mouth), if it is not necessary to supplement, check the oil level (ensure that the oil level is between the maximum and minimum value of the oil scale) to check whether the fuel is sufficient, whether there is leakage

2. Open the electric lock, press Manual, and then press Start for 2 seconds to release it. Open, the controller shows that the unit can be closed after normal operation, such as high water temperature, low oil pressure, overspeed, the control system will automatically alarm and automatic stop. Note: During the operation of the generator set, do not disconnect the battery from the generator set

3. Stop

After the completion of power generation, the load switch must be cut off first, that is, to disconnect the output switch, press the Stop button (Stop), and check whether the generator set has leakage after the shutdown delay of 40 seconds. When the generator set has an emergency situation, it is allowed to press the emergency Stop button.

4. Precautions:

Diesel generator set running 50-100 hours, need to replace the oil filter 15W-40, generator set running 250-300 hours, need to replace the diesel filter, oil filter, air filter
